IBH
1,000-2,000 lb. In-Between Handling Lift Truck
The original in-between handling vehicle, our IBH manual straddle stacker continues to be one of our most popular models. The simple design and functionality of the IBH make it a great choice for work positioning, transport and storage duties where powered lift is all you need.
Available in a wide variety of configurations and with optional add-on accessories the IBH can be specifically tailored to meet the needs of your application. When matched correctly to meet the mission the IBH can provide a huge amount of utility for little cost.
If you’re looking for a basic rugged vehicle that can accomplish a variety of tasks choose one of our Big Joe IBH manual straddle stackers. Our littlest truck may be our biggest value.
Available in a wide variety of configurations and with optional add-on accessories the IBH can be specifically tailored to meet the needs of your application. When matched correctly to meet the mission the IBH can provide a huge amount of utility for little cost.
If you’re looking for a basic rugged vehicle that can accomplish a variety of tasks choose one of our Big Joe IBH manual straddle stackers. Our littlest truck may be our biggest value.
- Features
- Specifications
- Videos
The IBH Features:
- 1,000 to 2,000lb. Capacity depending on vehicle configuration
- 12volt electrical power with built-in battery pack and charger
- Premium steel frame construction protects components and reduces maintenance.
- Premium steel mast construction provides extended service life and load stability.
- Compact vehicle design provides exceptional maneuverability in tight areas.
- Shaft type forks provide for easy adjustment.
- Chrome plated lift cylinder with pressure compensation lowering valves.
- A wide variety of vehicle options to meet your specific application needs.
- Optional add on attachments designed for a variety of special industry applications.
The IBH Specifications:
• Vehicle Type
|
Manual straddle stacker
|
• Capacity
|
1,000lbs. to 2,000lbs. @ 18” or 24” load center
|
• Power
|
12 volt electric with battery pack and charger
|
• Max Lift Height
|
Masts available from 57” to 144”
|
• Collapsed Height
|
Based on configuration and max lift height |
• Fork Dimensions
|
A wide variety of options available
|
• Vehicle Dimensions
|
Varies see media tab to download product sheet
|
• Turning Radius
|
As little as 46” up to 54.25” depending on model
|
• Battery Capacity
|
105AH / 125 AH/ 155AH available
|
• Charger
|
Internal included
|
